MODEL SPECS |
Click on a technology to learn more.
| Chassis Management Technology |
| Engine | 4-stroke, single cylinder, DOHC |
| Displacement | 652cc |
| Bore x Stroke | 100.0 x 83.0mm |
| Compression Ratio | 9.8:1 |
| Maximum Torque | 39.1 lb-ft @ 4,500 rpm |
| Fuel System | DFI® with 40mm throttle body |
| Ignition | CDI |
| Transmission | 5-speed, return shift with wet multi-disc manual clutch |
| Final Drive | Sealed chain |
| Electronic Rider Aids | Anti-lock Brake System (ABS) |
| Front Suspension / Wheel Travel | 41mm telescopic fork/ 7.9 in |
| Rear Suspension / Wheel Travel | Uni-Trak® single shock with adjustable rebound damping and adjustable spring preload/8.0 in |
| Front Tire | 90/90-21 |
| Rear Tire | 130/80-17 |
| Front Brakes | Single 300mm disc with 2-piston calipers (and ABS) |
| Rear Brakes | Single 240mm disc with single-piston caliper (and ABS) |
| Frame Type | Tubular, semi-double cradle |
| Rake/Trail | 30.0°/4.8 in |
| Overall Length | 89.8 in |
| Overall Width | 38.2 in |
| Overall Height | 57.7/56.3 in (screen hi/lo) |
| Ground Clearance | 8.3 in |
| Seat Height | 34.3 in |
| Estimated Dry Weight | 416.6 lb** (ABS), 412.1 lb** (non-ABS) |
| Curb Weight | 460.6 lb* (ABS), 456.2 lb* (non-ABS) |
| Fuel Capacity | 6.1 gal |
| Wheelbase | 60.6 in |
| Color Choices | Metallic Matte Old School Green, Pearl Crystal White/Metallic Carbon Gray |
| Warranty | 12 Month Limited Warranty |
*Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
**Dry weight does not include all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
KAWASAKI CARES: Read Owner’s Manual and all on-product warnings. Always wear protective gear appropriate for the use of this vehicle. Never operate under the influence of drugs or alcohol. Protect the environment. The Kawasaki MULE™ side x side is an off-highway vehicle only, and is not designed, equipped or manufactured for use on public streets, roads or highways. Obey the laws and regulations that control the use of your vehicle. ©2025 Kawasaki Motors Corp., U.S.A.
Specifications subject to change.
